CSC5180ZYS6EQ Model technical parameters | |||
Name: | CSC5180ZYS6EQ | Exterior size(mm): | 8440,8750,8980×2500×3100 |
Chassis: | EQ1185LJ9CDE | Container size(mm): | ×× |
Total weight :(kg) | 18000 | Approach angle/ Departure angle(° ) | 19/13 |
Payload:(kg) | 8270,8205,8070,8005,7570,7505 | Front suspension/rear suspension(mm): | 1260/2420,1260/2915 |
Kerb Mass:(kg) | 9600,9800,10300(Kg) | Max Speed(km/h): | 105 |
Chassis parameters | |||
Chassis: | EQ1185LJ9CDE | Axle weight: | 6500/11500 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3600,3950,4500,4700,5000,5300,5600 | Fronttread(mm): | 1862,1933,1949 |
Max people in cab: | 2,3 | Rear tread(mm): | 1806,1865 |
Number of tires: | 6 | Number of spring axle: | 8/10+7,8/- |
Tire Type: | 295/80R22.5 18PR,10.00R20 18PR,275/80R22.5 18PR | ||
introduction: | 1、该车主要专用装置由箱体、填料器总成、压缩系统等组成,用于垃圾的收集与清运。选装后部工作装置。整车外形长/后悬/后伸对应关系为(mm):8440/2420/260,8750/2420/570,8980/2915/305。仅采用4500mm轴距。2、侧防护材料采用铝合金,螺栓连接;后防护由专用装置代替,下边缘离地高:450mm。3、随底盘选装同系列的高顶驾驶室。随底盘选装底盘附件安装位置。安装带有卫星定位功能的行驶记录仪。ABS系统控制器型号/厂家:J ABS/焦作博瑞克控制技术有限公司。发动机与油耗值(L/100km)对应关系:B6.2NS6B210/26.3,CY4SK761/26.8,D4.0NS6B195/26.6,D4.5NS6B220/26.6,YCS04200-6826.4,B6.2NS6B230/26.1。 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
CY4SK761 YCS04200-68 D4.5NS6B220 YCY30165-60 B6.2NS6B210 B6.2NS6B230 D4.0NS6B195 YCY30170-60 |
东风朝阳朝柴动力有限公司 广西玉柴机器股份有限公司 东风康明斯发动机有限公司 广西玉柴机器股份有限公司 东风康明斯发动机有限公司 东风康明斯发动机有限公司 东风康明斯发动机有限公司 广西玉柴机器股份有限公司 |
4087 4156 4500 2970 6200 6200 4000 2970 |
145/197 147/199 162/220 121/164 154/209 169/229 143/194 125/170 |
